A21 light bulb (E26 base)

Name: A21 light bulb (E26 base) dimension sheet
Creator: Xem Studio
License: https://creativecommons.org/licenses/by/4.0/

What size is an A21 light bulb? · Modern device · basis: Philips product datasheet (Philips 16A21/PER/830/P/E26/DIM)

Also called: a21 bulb size, a21 dimensions, a21 light bulb dimensions, bombilla A21 medidas, lâmpada A21 dimensões, A21 Lampe Maße, ampoule A21 dimensions

Exact dimensions. True size, with no printing tolerance added.

length: 78 mm
width: 78 mm
height: 140 mm

Notes

A21: Ø78 mm, 140 mm maximum overall length, E26 base — figures from the Philips 16A21/PER/830/P/E26/DIM datasheet.
The shape code gives the diameter in eighths of an inch (A21); the ANSI C78 envelope limits are paywalled, so a typical current product is quoted. Other brands differ by a few mm in length.
The file is a cylinder envelope Ø × MOL (the bulb fits inside it).

A21 light bulb size chart

dimension	value
diameter	78 mm (3.07 in)
max overall length	140 mm (5.51 in)
base	E26
reference product	Philips 16A21/PER/830/P/E26/DIM

Where the files are

Other publishers' files are linked, not hosted. "verify" = check the license at the link before commercial use.

Philips

Philips 16A21/PER/830/P/E26/DIM datasheet

web

Publisher's page; dimensions are facts

Free files

★ Free files 1 parts. Generated by Xem Studio from the standard; threads are plain cylinders at major diameter. CC BY 4.0. index.json

a21-light-bulb-envelope

Envelope Ø78 × 140 mm

STEP · STL
