ARRMA Granite Grom 4X4 (1/18 monster truck, ARA2102)

What are the dimensions of the ARRMA Granite Grom 4X4? · Modern device · basis: Manufacturer specifications (ARRMA (Horizon Hobby))

Also called: arrma grom dimensions, granite grom size, grom wheelbase, arrma grom length, ara2102 specs, medidas arrma grom, arrma grom maße, arrma granite grom 4x4 specs, arrma granite grom 4x4 measurements

Exact dimensions. True size, with no printing tolerance added.

length
250 mm
width
200 mm
height
118 mm

Notes

  • The Granite Grom is ARRMA's 1/18 4WD mini monster truck. The file is its 250 × 200 × 118 mm envelope.
  • Battery bay, hex and tire sizes are not published.
  • True size, no printing tolerance added. Only published numbers are used; anything not published is said so.

ARRMA Granite Grom 4X4 size chart

dimensionvalue
Length9.84 in (250 mm)
Width7.87 in (200 mm)
Height4.65 in (118 mm)
Wheelbase6.5 in (165 mm)
Weight (with battery)1.77 lb (800 g)
Motor380 28T brushed
ESCSpektrum SLT 25A 2-in-1
ServoSpektrum SX110
BatterySpektrum Smart 7.4 V 1400 mAh 2S hard case

Where the files are

Other publishers' files are linked, not hosted. "verify" = check the license at the link before commercial use.

ARRMA (Horizon Hobby)ARRMA 1/18 Granite Grom 4X4 RTRwebPublisher's page; dimensions are facts

Free files

★ Free files 1 parts. Generated by Xem Studio from the standard; threads are plain cylinders at major diameter. CC BY 4.0. index.json

arrma-granite-grom-envelopeEnvelope 250 × 200 × 118 mm (Ready-to-run truck with body and wheels)STEP · STL
Let your AI pull this. Add https://xemstudio.com/mcp to Claude, ChatGPT, Cursor or any MCP client (free, no account, one minute) and it can look up exact sizes, mating fits and free STEP/STL from every chat.
Set it up →

Plain text: sheet.txt · JSON: /api/geometry?object=arrma-granite-grom

length
Schematic, not to scale.

Fits with

Traxxas TRX-4M Chevrolet K10 High Trail (1/18 crawler, 97064-1), isometric render of a generated part
Traxxas TRX-4M Chevrolet K10 High Trail (1/18 crawler, 97064-1)269×127 mm★ 1 file
length
Axial SCX24 2021 Ford Bronco (1/24 crawler, AXI00006)222×98×117 mm★ 1 file
length
Axial UTB18 Capra (1/18 trail buggy, AXI01002V2)320×196×150 mm★ 1 file
length
Losi Mini-T 2.0 Brushless (1/18 stadium truck, LOS01019)232×179×91 mm★ 1 file

Questions

How big is the Granite Grom?

250 mm long, 200 mm wide and 118 mm tall on a 165 mm wheelbase.
