Axial RBX10 Ryft 4X4 Rock Bouncer (1/10, AXI03005)

What are the dimensions of the Axial RBX10 Ryft 4X4 Rock Bouncer? · Modern device · basis: Manufacturer specifications (Axial (Horizon Hobby))

Also called: axial ryft dimensions, rbx10 size, ryft wheelbase, rbx10 ryft length, ryft shock length, axi03005 specs, medidas axial ryft, axial ryft maße, axial rbx10 ryft 4x4 rock bouncer specs

Exact dimensions. True size, with no printing tolerance added.

length
546 mm
width
324 mm
height
222 mm

Notes

  • The RBX10 Ryft is Axial's brushless 1/10 rock bouncer. The file is its 546 × 324 × 222 mm envelope.
  • Tire diameter, hex and battery tray size are not published.
  • True size, no printing tolerance added. Only published numbers are used; anything not published is said so.

Axial RBX10 Ryft 4X4 Rock Bouncer size chart

dimensionvalue
Length21.5 in (546 mm)
Width12.75 in (324 mm)
Height8.75 in (222 mm)
Wheelbase15.25 in (387.35 mm)
Front / rear track12.75 in (323.8 mm)
Ground clearance3.25 in (82.5 mm)
Weight7.26 lb (3.29 kg)
Wheel width1.6 in (40.64 mm)
Shocksfront 5.11 in (130 mm), rear 5.70 in (145 mm)
Motor3660 2200 Kv brushless
ESCSpektrum Firma 130A Smart
Battery3–4S LiPo, IC5

Where the files are

Other publishers' files are linked, not hosted. "verify" = check the license at the link before commercial use.

Axial (Horizon Hobby)1/10 RBX10 Ryft 4X4 RTR AXI03005webPublisher's page; dimensions are facts

Free files

★ Free files 1 parts. Generated by Xem Studio from the standard; threads are plain cylinders at major diameter. CC BY 4.0. index.json

axial-rbx10-ryft-envelopeEnvelope 546 × 324 × 222 mm (Ready-to-run truck with body and wheels)STEP · STL
Let your AI pull this. Add https://xemstudio.com/mcp to Claude, ChatGPT, Cursor or any MCP client (free, no account, one minute) and it can look up exact sizes, mating fits and free STEP/STL from every chat.
Set it up →

Plain text: sheet.txt · JSON: /api/geometry?object=axial-rbx10-ryft

length
Schematic, not to scale.

Fits with

length
Traxxas TRX-4 2021 Ford Bronco (1/10 crawler, 92076-4)584×249×239 mm★ 1 file
Traxxas TRX-6 Mercedes-Benz G 63 AMG 6x6 (1/10 crawler, 88096-4), isometric render of a generated part
Traxxas TRX-6 Mercedes-Benz G 63 AMG 6x6 (1/10 crawler, 88096-4)651×274 mm★ 1 file
length
Axial SCX10 III Jeep JLU Wrangler (1/10 crawler, AXI03003)486×235×241 mm★ 1 file
length
Axial Capra 1.9 4WS Unlimited Trail Buggy (1/10, AXI03022B)432×260×210 mm★ 1 file

Questions

What is the RBX10 Ryft's wheelbase?

387.35 mm (15.25 in) with 323.8 mm track.
