Du-Bro 2-56 threaded pushrod 12 in with nylon Kwik-Link (DUB123)

Name: Du-Bro 2-56 threaded pushrod 12 in with nylon Kwik-Link (DUB123) dimension sheet
Creator: Xem Studio
License: https://creativecommons.org/licenses/by/4.0/

What are the dimensions of the Du-Bro 2-56 threaded pushrod 12 in with nylon Kwik-Link? · Modern device · basis: Secondary source: ReadyMadeRC (retailer) (copy of the maker's figures; the maker publishes none directly)

Also called: 2-56 pushrod diameter, dubro 2-56 rod, dub123, 0.072 pushrod wire, 1.8mm pushrod, rc pushrod size, varilla 2-56, schubstange 2-56

Exact dimensions. True size, with no printing tolerance added.

length: 1.82 mm
width: 1.82 mm
height: 305 mm

Notes

Retailer copy of Du-Bro data (secondary). The cylinder is the rod only; the nylon Kwik-Link on the end is not modelled.
True size, no printing tolerance added. Only published numbers are used; anything not published is said so.
Secondary source: the numbers come from a retailer or magazine copy of the maker's specification.

Du-Bro 2-56 threaded pushrod 12 in with nylon Kwik-Link size chart

dimension	value
Rod length	12 in (305 mm)
Rod diameter	0.072 in (1.82 mm)
Thread	2-56, ~3/4 in (19 mm) long

Where the files are

Other publishers' files are linked, not hosted. "verify" = check the license at the link before commercial use.

ReadyMadeRC (retailer)

DuBro Nylon Kwik-Link on 12" 2-56 Rod

web

Publisher's page; dimensions are facts

Free files

★ Free files 1 parts. Generated by Xem Studio from the standard; threads are plain cylinders at major diameter. CC BY 4.0. index.json

du-bro-2-56-threaded-rod-12in-envelope

Envelope Ø1.82 × 305 mm (Rod diameter × rod length (link not included))

STEP · STL

Let your AI pull this. Add https://xemstudio.com/mcp to Claude, ChatGPT, Cursor or any MCP client (free, no account, one minute) and it can look up exact sizes, mating fits and free STEP/STL from every chat.

Set it up →

Plain text: sheet.txt · JSON: /api/geometry?object=du-bro-2-56-threaded-rod-12in

Du-Bro 2-56 threaded pushrod 12 in with nylon Kwik-Link (DUB123), isometric render of a generated part — Render of du-bro-2-56-threaded-rod-12in-envelope from the free STEP; not to scale.

Fits with

Free

Du-Bro Safety Lock Kwik-Link 2-56 (DUB815), isometric render of a generated part

Du-Bro Safety Lock Kwik-Link 2-56 (DUB815)28.57×7.94 mm★ 1 file

Questions

What diameter is a 2-56 pushrod?

Du-Bro lists 0.072 in (1.82 mm) for its 2-56 threaded rod.
