Freewing F-16 Falcon V3 70mm EDF jet

What are the dimensions of the Freewing F-16 Falcon V3 70mm EDF jet? · Modern device · basis: Secondary source: Lindinger (retailer) (copy of the maker's figures; the maker publishes none directly)

Also called: freewing f-16 dimensions, freewing f16 70mm wingspan, f-16 v3 length, freewing f16 weight, f-16 70mm battery, fj21115, f-16 falcon spannweite, f-16 falcon envergadura

Exact dimensions. True size, with no printing tolerance added.

length
1306 mm
width
878 mm

Notes

  • Specs from Lindinger's listing of the Freewing F-16 V3 70mm PNP (secondary).
  • Plan-view envelope only (wingspan × length); height and wing area are not published.
  • True size, no printing tolerance added. Only published numbers are used; anything not published is said so.
  • Secondary source: the numbers come from a retailer or magazine copy of the maker's specification.

Freewing F-16 Falcon V3 70mm EDF jet size chart

dimensionvalue
Wingspan878 mm
Length1306 mm
Empty weightapprox. 1450 g
EDF70 mm 12-blade
Motor2957 inrunner (table 2100 Kv; text 2210 Kv)
ESC80 A with 5 A UBEC, EC5
Servos6 × 9 g digital hybrid
Battery6S 2600–4000 mAh
Heightnot published

Where the files are

Other publishers' files are linked, not hosted. "verify" = check the license at the link before commercial use.

Lindinger (retailer)Freewing F-16 70mm V3 EDF Jet PNPwebPublisher's page; dimensions are facts

Free files

★ Free files 1 parts. Generated by Xem Studio from the standard; threads are plain cylinders at major diameter. CC BY 4.0. index.json

freewing-f-16-falcon-v3-70mm-edf-plan-outlinePlan outline 1306 × 878 mm, 1 mm reference thickness (height not published)STEP · STL
Let your AI pull this. Add https://xemstudio.com/mcp to Claude, ChatGPT, Cursor or any MCP client (free, no account, one minute) and it can look up exact sizes, mating fits and free STEP/STL from every chat.
Set it up →

Plain text: sheet.txt · JSON: /api/geometry?object=freewing-f-16-falcon-v3-70mm-edf

Freewing F-16 Falcon V3 70mm EDF jet, isometric render of a generated part
Render of freewing-f-16-falcon-v3-70mm-edf-plan-outline from the free STEP; not to scale.

Fits with

RC LiPo battery sizes: ROAR 2S hardcase, shorty, saddle, 4S brick; drone 4S / 6S and 3S 2200 packs; connectors, isometric render of a generated part
RC LiPo battery sizes: ROAR 2S hardcase, shorty, saddle, 4S brick; drone 4S / 6S and 3S 2200 packs; connectors12 sizes★ 4 files
Freewing F-86 Sabre 80mm EDF jet, isometric render of a generated part
Freewing F-86 Sabre 80mm EDF jet1200×1200 mm★ 1 file
Freewing F-22 Raptor 90mm EDF jet, isometric render of a generated part
Freewing F-22 Raptor 90mm EDF jet1500×1060 mm★ 1 file
Freewing A-10 Thunderbolt II V3 twin 64mm EDF, isometric render of a generated part
Freewing A-10 Thunderbolt II V3 twin 64mm EDF1143×1270 mm★ 1 file
Freewing F9F-8 Cougar 80mm EDF jet, isometric render of a generated part
Freewing F9F-8 Cougar 80mm EDF jet1436×1050 mm★ 1 file

Questions

What battery fits the Freewing F-16 V3?

Lindinger lists 6S 2600–4000 mAh.
