FrSky Archer RS receiver

Name: FrSky Archer RS receiver dimension sheet
Creator: Xem Studio
License: https://creativecommons.org/licenses/by/4.0/

What are the dimensions of the FrSky Archer RS receiver? · Modern device · basis: Secondary source: GetFPV (retailer) (copy of the maker's figures; the maker publishes none directly)

Also called: archer rs dimensions, frsky archer rs size, archer rs mm, archer rs weight, archer rs ota size, frsky archer receiver dimensions, archer rs medidas, archer rs abmessungen

Exact dimensions. True size, with no printing tolerance added.

length: 16 mm
width: 11 mm
height: 2.5 mm

Notes

Retailer copy of FrSky specs (secondary).
True size, no printing tolerance added. Only published numbers are used; anything not published is said so.
Secondary source: the numbers come from a retailer or magazine copy of the maker's specification.

FrSky Archer RS receiver size chart

dimension	value
Dimensions	16 × 11 × 2.5 mm (L × W × H)
Weight	1.3 g
Channels	16/24 SBUS
Voltage	3.5–10 V
Antenna	dual detachable

Where the files are

Other publishers' files are linked, not hosted. "verify" = check the license at the link before commercial use.

GetFPV (retailer)

FrSky ARCHER RS OTA 2.4GHz Receiver

web

Publisher's page; dimensions are facts

Free files

★ Free files 1 parts. Generated by Xem Studio from the standard; threads are plain cylinders at major diameter. CC BY 4.0. index.json

frsky-archer-rs-receiver-envelope

Envelope 16 × 11 × 2.5 mm (Receiver case L × W × H, antennas and pins excluded)

STEP · STL

Let your AI pull this. Add https://xemstudio.com/mcp to Claude, ChatGPT, Cursor or any MCP client (free, no account, one minute) and it can look up exact sizes, mating fits and free STEP/STL from every chat.

Set it up →

Plain text: sheet.txt · JSON: /api/geometry?object=frsky-archer-rs-receiver

Schematic, not to scale.
