HC-SR04 ultrasonic sensor

What are the dimensions of the HC-SR04 ultrasonic sensor? · Modern device · basis: ElecFreaks datasheet (mirror)

Also called: hc-sr04 ultrasonic sensor dimensions, hc-sr04 ultrasonic sensor size, hc-sr04 ultrasonic sensor mounting holes, hc-sr04 ultrasonic sensor medidas, hc-sr04 ultrasonic sensor Maße

Exact dimensions. True size, with no printing tolerance added.

length
45 mm
width
20 mm
height
15 mm

Notes

  • HC-SR04 ultrasonic sensor: 45 × 20 × 15 mm. Published 45 × 20 × 15 mm. Transducer spacing and holes are not published, and clones vary (scan planned).
  • No mounting-hole positions are published.
  • The file is the outline; components and connectors are not modelled.

HC-SR04 ultrasonic sensor size chart

dimensionvalue
size45 × 20 × 15 mm
