HQProp Cine7 7x4x3 propeller (glass-fibre nylon)

What are the dimensions of the HQProp Cine7 7x4x3 propeller (glass-fibre nylon)? · Modern device · basis: Secondary source: KiwiQuads (copy of the maker's figures; the maker publishes none directly)

Also called: HQProp Cine7 dimensions, HQProp Cine7 hub thickness, HQProp Cine7 bore, HQProp Cine7 weight, HQProp Cine7 shaft size, HQProp Cine7 specs, dimensiones hélice HQProp Cine7, HQProp Cine7 Propeller Abmessungen, HQ Cine7 hub diameter, HQ 7x4x3 nylon

Exact dimensions. True size, with no printing tolerance added.

length
177.8 mm
width
177.8 mm
height
6.8 mm

Notes

  • Stiffer nylon 7 in prop.
  • The file is a Ø177.8 swept disc with a Ø13 × 6.8 mm hub.
  • True size, no printing tolerance added. Only published numbers are used; anything not published is said so.
  • Secondary source: the numbers come from a retailer or magazine copy of the maker's specification.

HQProp Cine7 7x4x3 propeller size chart

dimensionvalue
Diameter7 in (177.8 mm)
Pitch4 in
Hub thickness6.8 mm
Bore / mount5 mm shaft
Weight10.3 g
Hub diameter13 mm
Materialglass-fibre reinforced nylon

Where the files are

Other publishers' files are linked, not hosted. "verify" = check the license at the link before commercial use.

KiwiQuadsHQProp Cine7 7X4X3 Glass Fiber Reinforced NylonwebPublisher's page; dimensions are facts

Free files

★ Free files 1 parts. Generated by Xem Studio from the standard; threads are plain cylinders at major diameter. CC BY 4.0. index.json

hqprop-cine7-7x4x3-swept-discSwept disc Ø177.8 mm × 6.8 mm hub thickness, Ø5 mm bore — blades not modelledSTEP · STL
Let your AI pull this. Add https://xemstudio.com/mcp to Claude, ChatGPT, Cursor or any MCP client (free, no account, one minute) and it can look up exact sizes, mating fits and free STEP/STL from every chat.
Set it up →

Plain text: sheet.txt · JSON: /api/geometry?object=hqprop-cine7-7x4x3

HQProp Cine7 7x4x3 propeller (glass-fibre nylon), isometric render of a generated part
Render of hqprop-cine7-7x4x3-swept-disc from the free STEP; not to scale.

Fits with

FPV drone motor sizes: 1104 to 3115, shaft, prop thread and mount patterns, isometric render of a generated part
FPV drone motor sizes: 1104 to 3115, shaft, prop thread and mount patterns12 sizes★ 10 files
APC 8x4E electric propeller, isometric render of a generated part
APC 8x4E electric propeller203.2×203.2×8.89 mm★ 2 files
APC 8x6E electric propeller, isometric render of a generated part
APC 8x6E electric propeller203.2×203.2×9.91 mm★ 2 files
APC 9x4.5E electric propeller, isometric render of a generated part
APC 9x4.5E electric propeller228.6×228.6×9.65 mm★ 2 files
APC 9x6E electric propeller, isometric render of a generated part
APC 9x6E electric propeller228.6×228.6×9.91 mm★ 2 files

Questions

What shaft does the HQProp Cine7 7x4x3 propeller (glass-fibre nylon) fit?

Bore/mount: 5 mm shaft; hub thickness 6.8 mm.
