HQProp DP 7x4x3 propeller

What are the dimensions of the HQProp DP 7x4x3 propeller? · Modern device · basis: Secondary source: GetFPV (copy of the maker's figures; the maker publishes none directly)

Also called: HQProp 7x4x3 dimensions, HQProp 7x4x3 hub thickness, HQProp 7x4x3 bore, HQProp 7x4x3 weight, HQProp 7x4x3 shaft size, HQProp 7x4x3 specs, dimensiones hélice HQProp 7x4x3, HQProp 7x4x3 Propeller Abmessungen, HQ 7 inch prop, 7040 tri blade

Exact dimensions. True size, with no printing tolerance added.

length
177.8 mm
width
177.8 mm
height
7 mm

Notes

  • 7 in long-range tri-blade.
  • Hub diameter not listed.
  • True size, no printing tolerance added. Only published numbers are used; anything not published is said so.
  • Secondary source: the numbers come from a retailer or magazine copy of the maker's specification.

HQProp DP 7x4x3 propeller size chart

dimensionvalue
Diameter7 in (177.8 mm)
Pitch4 in
Hub thickness7 mm
Bore / mount5 mm mounting hole
Weight9.27 g
Materialpolycarbonate

Where the files are

Other publishers' files are linked, not hosted. "verify" = check the license at the link before commercial use.

GetFPVHQProp DP 7X4X3 PropellerwebPublisher's page; dimensions are facts

Free files

★ Free files 1 parts. Generated by Xem Studio from the standard; threads are plain cylinders at major diameter. CC BY 4.0. index.json

hqprop-dp-7x4x3-swept-discSwept disc Ø177.8 mm × 7 mm hub thickness, Ø5 mm bore — blades not modelledSTEP · STL
Let your AI pull this. Add https://xemstudio.com/mcp to Claude, ChatGPT, Cursor or any MCP client (free, no account, one minute) and it can look up exact sizes, mating fits and free STEP/STL from every chat.
Set it up →

Plain text: sheet.txt · JSON: /api/geometry?object=hqprop-dp-7x4x3

HQProp DP 7x4x3 propeller, isometric render of a generated part
Render of hqprop-dp-7x4x3-swept-disc from the free STEP; not to scale.

Fits with

FPV drone motor sizes: 1104 to 3115, shaft, prop thread and mount patterns, isometric render of a generated part
FPV drone motor sizes: 1104 to 3115, shaft, prop thread and mount patterns12 sizes★ 10 files
APC 8x4E electric propeller, isometric render of a generated part
APC 8x4E electric propeller203.2×203.2×8.89 mm★ 2 files
APC 8x6E electric propeller, isometric render of a generated part
APC 8x6E electric propeller203.2×203.2×9.91 mm★ 2 files
APC 9x4.5E electric propeller, isometric render of a generated part
APC 9x4.5E electric propeller228.6×228.6×9.65 mm★ 2 files
APC 9x6E electric propeller, isometric render of a generated part
APC 9x6E electric propeller228.6×228.6×9.91 mm★ 2 files

Questions

What shaft does the HQProp DP 7x4x3 propeller fit?

Bore/mount: 5 mm mounting hole; hub thickness 7 mm.
