IKEA PAX wardrobe frame dimensions (50, 75, 100 wide; 201, 236 high; 35, 58 deep)
What are the IKEA PAX frame dimensions? · Modern device · basis: IKEA product pages
Also called: pax dimensions, pax frame sizes, pax wardrobe measurements
Exact dimensions. True size, with no printing tolerance added.
- sizes
- 3 in table
Notes
- Titles are nominal: a '100' frame measures 998 wide, '201' measures 2012 high, '236' 2364.
- Widths 50 / 75 / 100, heights 201 / 236, depths 35 / 58; corner unit 53 × 58 × 236.
IKEA PAX wardrobe frame dimensions size chart
| frame | width (mm) | depth (mm) | height (mm) |
|---|---|---|---|
| PAX 50 × 35 × 201 | 498 | 355 | 2012 |
| PAX 75 × 58 × 201 | 748 | 580 | 2012 |
| PAX 100 × 58 × 236 | 998 | 580 | 2364 |
Where the files are
Other publishers' files are linked, not hosted. "verify" = check the license at the link before commercial use.
| IKEA (official product page) | PAX 50x35x201 | web | Manufacturer product page; dimensions are facts |
| IKEA (official product page) | PAX 75x58x201 | web | Manufacturer product page; dimensions are facts |
| IKEA (official product page) | PAX 100x58x236 | web | Manufacturer product page; dimensions are facts |
Xem scan
Not planned The manufacturer publishes CAD; the sheet is here so an assistant can answer without opening a PDF.
Let your AI pull this. Add
Set it up →https://xemstudio.com/mcp to Claude, ChatGPT, Cursor or any MCP client (free, no account, one minute) and it can look up exact sizes, mating fits and free STEP/STL from every chat.Plain text: sheet.txt · JSON: /api/geometry?object=ikea-pax
Questions
How deep is a PAX wardrobe?
580 mm (58 cm frames) or 355 mm (35 cm frames).
