Spektrum AR620 6-channel sport receiver

Name: Spektrum AR620 6-channel sport receiver dimension sheet
Creator: Xem Studio
License: https://creativecommons.org/licenses/by/4.0/

What are the dimensions of the Spektrum AR620 6-channel sport receiver? · Modern device · basis: Secondary source: HobbyEtc (retailer) (copy of the maker's figures; the maker publishes none directly)

Also called: ar620 dimensions, spektrum ar620 size, spmar620, ar620 receiver mm, ar620 weight, ar620 internal antenna, ar620 medidas, ar620 abmessungen

Exact dimensions. True size, with no printing tolerance added.

length: 32.1 mm
width: 26.4 mm
height: 17.9 mm

Notes

Retailer copy of Spektrum specs (secondary).
True size, no printing tolerance added. Only published numbers are used; anything not published is said so.
Secondary source: the numbers come from a retailer or magazine copy of the maker's specification.

Spektrum AR620 6-channel sport receiver size chart

dimension	value
Length	1.26 in (32.1 mm)
Width	1.04 in (26.4 mm)
Height	0.71 in (17.9 mm)
Weight	0.28 oz (8 g)
Channels	6
Voltage	3.5–9 V
Antenna	internal

Where the files are

Other publishers' files are linked, not hosted. "verify" = check the license at the link before commercial use.

HobbyEtc (retailer)

AR620 6 Channel Sport Receiver

web

Publisher's page; dimensions are facts

Free files

★ Free files 1 parts. Generated by Xem Studio from the standard; threads are plain cylinders at major diameter. CC BY 4.0. index.json

spektrum-ar620-receiver-envelope

Envelope 32.1 × 26.4 × 17.9 mm (Receiver case L × W × H, antennas and pins excluded)

STEP · STL
