Traxxas 5120A ball bearing, 12 × 18 × 4 mm

What size is Traxxas bearing 5120A? · Modern device · basis: Maker's parts list (Traxxas)

Also called: Traxxas 5120A, traxxas 5120A, Traxxas part 5120A, 5120A ball bearings, black rubber sealed (12x18x4mm), Traxxas 5120A size, Traxxas 5120A dimensions, Traxxas 5120A replacement, repuesto Traxxas 5120A, Traxxas 5120A Ersatzteil

Exact dimensions. True size, with no printing tolerance added.

length
18.01 mm
width
18.01 mm
height
4.01 mm

Notes

  • Traxxas part 5120A: Ball bearings, black rubber sealed (12x18x4mm) (2). Size exactly as printed in Traxxas's parts list; the file is built from that size only.
  • Bearing envelope 12 × 18 × 4 mm (bore × OD × width).
  • True size, no printing tolerance added.

Traxxas 5120A ball bearing, 12 × 18 × 4 mm size chart

dimensionvalue
part numberTraxxas 5120A
name (as printed)Ball bearings, black rubber sealed (12x18x4mm) (2)
size (as printed)12x18x4mm
bore12 mm
outside diameter18 mm
width4 mm
seals / ballsas printed in the name; not modelled
used inTraxxas TRX-4 2021 Ford Bronco (1/10 crawler, 92076-4)

Where the files are

Other publishers' files are linked, not hosted. "verify" = check the license at the link before commercial use.

Traxxas (sheet hosted by Monsterhopups)TRX-4 Unassembled Kit (Model 82016-4) parts list, REV. 230615 0246, p. 1webPublisher's page; dimensions are facts

Free files

★ Free files 1 parts. Generated by Xem Studio from the standard; threads are plain cylinders at major diameter. CC BY 4.0. index.json

traxxas-5120a-ball-bearings-black-rubber-sealed-12x18x4mm-envelopeBearing envelope 12 × 18 × 4 mm (bore × OD × width)STEP · STL
Let your AI pull this. Add https://xemstudio.com/mcp to Claude, ChatGPT, Cursor or any MCP client (free, no account, one minute) and it can look up exact sizes, mating fits and free STEP/STL from every chat.
Set it up →

Plain text: sheet.txt · JSON: /api/geometry?object=traxxas-5120a-ball-bearings-black-rubber-sealed-12x18x4mm

Traxxas 5120A ball bearing, 12 × 18 × 4 mm, isometric render of a generated part
Render of traxxas-5120a-ball-bearings-black-rubber-sealed-12x18x4mm-envelope from the free STEP; not to scale.

Fits with

Traxxas TRX-4 kit (82016-4) parts list, isometric render of a generated part
Traxxas TRX-4 kit (82016-4) parts list584×249×239 mm★ 47 files
length
Traxxas TRX-4 2021 Ford Bronco (1/10 crawler, 92076-4)584×249×239 mm★ 1 file
Ball bearings, 683 to 6210 and flanged F6xx (ISO 15), isometric render of a generated part
Ball bearings, 683 to 6210 and flanged F6xx (ISO 15)44 sizes★ 44 files

Questions

What size is Traxxas bearing 5120A?

12 × 18 × 4 mm
