BIGTREETECH TMC2209 stepper driver

What are the dimensions of the BIGTREETECH TMC2209 stepper driver? · Modern device · basis: BIGTREETECH (V1.2 manual)

Also called: bigtreetech tmc2209 stepper driver dimensions, bigtreetech tmc2209 stepper driver size, bigtreetech tmc2209 stepper driver mounting holes, bigtreetech tmc2209 stepper driver medidas, bigtreetech tmc2209 stepper driver Maße

Exact dimensions. True size, with no printing tolerance added.

length
15.24 mm
width
20.32 mm

Notes

  • BIGTREETECH TMC2209 stepper driver: 15.24 × 20.32 mm. Figures from the V1.2 manual (no V1.3 manual found). StepStick 2 × 8 header, no mounting holes; cooling pad 8.81 × 10.19 mm.
  • No mounting-hole positions are published.
  • The file is the outline; components and connectors are not modelled.

BIGTREETECH TMC2209 stepper driver size chart

dimensionvalue
size15.24 × 20.32 mm (board outline)

Where the files are

Other publishers' files are linked, not hosted. "verify" = check the license at the link before commercial use.

BIGTREETECHBIGTREETECH TMC2209 stepper driverwebPublisher's page; dimensions are facts

Free files

★ Free files 1 parts. Generated by Xem Studio from the standard; threads are plain cylinders at major diameter. CC BY 4.0. index.json

bigtreetech-tmc2209-stepper-driver-outline15.24 × 20.32 mm; 1.6 mm plate (thickness not published)STEP · STL
Let your AI pull this. Add https://xemstudio.com/mcp to Claude, ChatGPT, Cursor or any MCP client (free, no account, one minute) and it can look up exact sizes, mating fits and free STEP/STL from every chat.
Set it up →

Plain text: sheet.txt · JSON: /api/geometry?object=bigtreetech-tmc2209-stepper-driver

BIGTREETECH TMC2209 stepper driver, isometric render of a generated part
Render of bigtreetech-tmc2209-stepper-driver-outline from the free STEP; not to scale.
