E-flite A-10 Thunderbolt II twin 64mm EDF

What are the dimensions of the E-flite A-10 Thunderbolt II twin 64mm EDF? · Modern device · basis: Secondary source: RC Visions (retailer) (copy of the maker's figures; the maker publishes none directly)

Also called: e-flite a-10 dimensions, e-flite a10 64mm wingspan, e-flite a-10 length, a-10 1149mm, e-flite a10 cg, e-flite a-10 battery, e-flite a10 spannweite, e-flite a10 envergadura

Exact dimensions. True size, with no printing tolerance added.

length
1061 mm
width
1149 mm

Notes

  • Retailer copy of Horizon's spec sheet (secondary).
  • Plan-view envelope only (wingspan × length); height and wing area are not published.
  • True size, no printing tolerance added. Only published numbers are used; anything not published is said so.
  • Secondary source: the numbers come from a retailer or magazine copy of the maker's specification.

E-flite A-10 Thunderbolt II twin 64mm EDF size chart

dimensionvalue
Wingspan45.24 in (1149 mm)
Length41.77 in (1061 mm)
Weight82 oz (2324 g) with 6S 4000 mAh; 61 oz (1732 g) without battery
Fanstwin 64 mm 11-blade
Motors2 × 2840 2200 Kv
ESCAvian dual 40 A Smart
Servos9 digital (installed)
Battery6S 3200–4000 mAh
CG2-3/16–2-3/4 in (55–70 mm) from wing leading edge at fuselage
Heightnot published

Where the files are

Other publishers' files are linked, not hosted. "verify" = check the license at the link before commercial use.

RC Visions (retailer)E-flite A-10 Thunderbolt II Twin 64mm EDF BNF BasicwebPublisher's page; dimensions are facts

Free files

★ Free files 1 parts. Generated by Xem Studio from the standard; threads are plain cylinders at major diameter. CC BY 4.0. index.json

e-flite-a-10-thunderbolt-ii-twin-64mm-plan-outlinePlan outline 1061 × 1149 mm, 1 mm reference thickness (height not published)STEP · STL
Let your AI pull this. Add https://xemstudio.com/mcp to Claude, ChatGPT, Cursor or any MCP client (free, no account, one minute) and it can look up exact sizes, mating fits and free STEP/STL from every chat.
Set it up →

Plain text: sheet.txt · JSON: /api/geometry?object=e-flite-a-10-thunderbolt-ii-twin-64mm

E-flite A-10 Thunderbolt II twin 64mm EDF, isometric render of a generated part
Render of e-flite-a-10-thunderbolt-ii-twin-64mm-plan-outline from the free STEP; not to scale.

Fits with

RC LiPo battery sizes: ROAR 2S hardcase, shorty, saddle, 4S brick; drone 4S / 6S and 3S 2200 packs; connectors, isometric render of a generated part
RC LiPo battery sizes: ROAR 2S hardcase, shorty, saddle, 4S brick; drone 4S / 6S and 3S 2200 packs; connectors12 sizes★ 4 files
Freewing F-86 Sabre 80mm EDF jet, isometric render of a generated part
Freewing F-86 Sabre 80mm EDF jet1200×1200 mm★ 1 file
Freewing F-22 Raptor 90mm EDF jet, isometric render of a generated part
Freewing F-22 Raptor 90mm EDF jet1500×1060 mm★ 1 file
Freewing A-10 Thunderbolt II V3 twin 64mm EDF, isometric render of a generated part
Freewing A-10 Thunderbolt II V3 twin 64mm EDF1143×1270 mm★ 1 file
Freewing F-16 Falcon V3 70mm EDF jet, isometric render of a generated part
Freewing F-16 Falcon V3 70mm EDF jet1306×878 mm★ 1 file

Questions

Where is the E-flite A-10 CG?

55–70 mm (2-3/16–2-3/4 in) back from the leading edge at the fuselage.
