FMS Ranger 1220mm (trainer with floats) parts list
What parts does the FMS Ranger 1220mm (trainer with floats) use, and what sizes are they? · Modern device · basis: Maker's manual / official spare-parts listing: part numbers and sizes as printed
Also called: FMS Ranger 1220mm (trainer with floats) part numbers, FMS Ranger 1220mm (trainer with floats) replacement parts, FMS Ranger 1220mm (trainer with floats) spare parts, FMS Ranger 1220mm (trainer with floats) parts diagram, FMS Ranger 1220mm (trainer with floats) exploded view, FMS Ranger 1220mm (trainer with floats) bearings, FMS Ranger 1220mm (trainer with floats) screw sizes, repuestos FMS Ranger
Exact dimensions. True size, with no printing tolerance added.
- length
- 947 mm
- width
- 1220 mm
Notes
- Every part number the maker publishes for the FMS Ranger 1220mm (trainer with floats) — 23 parts, 4 with sizes printed in the source (bearings, screws, pins, props, servos, motors, batteries…). Sizes are copied exactly as printed; "not published" means the source gives none.
- The file is the vehicle's own true-size envelope (the same as its main page). Molded parts' shapes are not published, so they are not modelled; standard hardware links to its own pages.
- Use it to rebuild or re-print the vehicle: order the numbered parts, print the rest to the published sizes.
FMS Ranger 1220mm (trainer with floats) parts list size chart
| part number | part | group | sizes (as printed) | qty | also fits |
|---|---|---|---|---|---|
| FMSES101RD | Front Fuselage | airframe | not published | not published | — |
| FMSES104RD | Battery cover | airframe | not published | not published | — |
| FMSES105RD | Cowl | airframe | not published | not published | — |
| FMSES116RD | Decal sheet | airframe | not published | not published | — |
| FMSES102RD | Main wing set | wing | not published | not published | — |
| FMSES117 | Wing Pipe | wing | not published | not published | — |
| FMSRN108 | Wing bolt plate | wing | not published | not published | — |
| FMSRN113 | Wing strut set | wing | not published | not published | — |
| FMSES103RD | Horizontal stabilizer | tail | not published | not published | — |
| FMSRN109 | Front landing gear set | landing gear | not published | not published | — |
| FMSRN110 | Main landing gear set | landing gear | not published | not published | — |
| FMSRN115 | Wheel set | landing gear | not published | not published | — |
| FMSBMX036 | Motor board | power system | not published | not published | — |
| FMSDJX009 | Motor mount | power system | not published | not published | — |
| FMSDZX018 | Motor shaft | power system | not published | not published | — |
| FMSPROP022 | Propeller | power system | not published | not published | — |
| FMSRN107 | Spinner | power system | not published | not published | — |
| PRESC004-1 | 20A ESC | power system | 20A | not published | — |
| PRKVX1200 | 3136-KV1200 Motor | power system | 3136, KV1200 | not published | — |
| FMSES112 | Linkage rods | servos/linkages | not published | not published | — |
| FMSSER003 | 9g digital gear servo positive | servos/linkages | 9g | not published | — |
| FMSSER010 | 9g digital gear servo positive (waterproof version) | servos/linkages | 9g | not published | — |
| FMSES114 | Screws set | hardware | not published | not published | — |
Where the files are
Other publishers' files are linked, not hosted. "verify" = check the license at the link before commercial use.
| FMS (manual hosted by Lindinger) | FMS 1220mm Ranger V2 manual (MAN-G0275), Spare Parts List, p. 13 | web | Publisher's page; dimensions are facts |
Free files
★ Free files 1 parts. Generated by Xem Studio from the standard; threads are plain cylinders at major diameter. CC BY 4.0. index.json
| fms-ranger-1220mm-plan-outline | Plan outline 947 × 1220 mm, 1 mm reference thickness (height not published) | STEP · STL |
