Pololu DRV8825 stepper driver carrier

What are the dimensions of the Pololu DRV8825 stepper driver carrier? · Modern device · basis: Pololu (dimension drawing)

Also called: pololu drv8825 stepper driver carrier dimensions, pololu drv8825 stepper driver carrier size, pololu drv8825 stepper driver carrier mounting holes, pololu drv8825 stepper driver carrier medidas, pololu drv8825 stepper driver carrier Maße

Exact dimensions. True size, with no printing tolerance added.

length
15.24 mm
width
20.32 mm

Notes

  • Pololu DRV8825 stepper driver carrier: 15.24 × 20.32 mm, 1.6 g. 0.6 × 0.8 in StepStick size; no mounting holes. Pololu also publishes a STEP model.
  • Mounting holes: 16 × Ø1.02 mm pin holes on 2.54 mm pitch, rows 12.70 mm apart, 1.27 mm from the edge.
  • The file is the outline; components and connectors are not modelled.

Pololu DRV8825 stepper driver carrier size chart

dimensionvalue
size15.24 × 20.32 mm (board outline)
mounting holes16 × Ø1.02 mm pin holes on 2.54 mm pitch, rows 12.70 mm apart, 1.27 mm from the edge
weight1.6 g

Where the files are

Other publishers' files are linked, not hosted. "verify" = check the license at the link before commercial use.

PololuPololu DRV8825 stepper driver carrierwebPublisher's page; dimensions are facts

Free files

★ Free files 1 parts. Generated by Xem Studio from the standard; threads are plain cylinders at major diameter. CC BY 4.0. index.json

pololu-drv8825-stepper-driver-carrier-outline15.24 × 20.32 mm; 1.6 mm plate (thickness not published)STEP · STL
Let your AI pull this. Add https://xemstudio.com/mcp to Claude, ChatGPT, Cursor or any MCP client (free, no account, one minute) and it can look up exact sizes, mating fits and free STEP/STL from every chat.
Set it up →

Plain text: sheet.txt · JSON: /api/geometry?object=pololu-drv8825-stepper-driver-carrier

Pololu DRV8825 stepper driver carrier, isometric render of a generated part
Render of pololu-drv8825-stepper-driver-carrier-outline from the free STEP; not to scale.

Fits with

Ai-Thinker ESP32-CAM, isometric render of a generated part
Ai-Thinker ESP32-CAM27×40.5×4.5 mm★ 1 file
HC-SR04 ultrasonic sensor, isometric render of a generated part
HC-SR04 ultrasonic sensor45×20×15 mm★ 1 file
Adafruit BME280 breakout (original), isometric render of a generated part
Adafruit BME280 breakout (original)17.78×19.05 mm★ 1 file
Adafruit 0.96 in 128x64 OLED (STEMMA QT), isometric render of a generated part
Adafruit 0.96 in 128x64 OLED (STEMMA QT)29.21×31.75×6.2 mm★ 1 file
Adafruit PCA9685 16-channel PWM servo driver, isometric render of a generated part
Adafruit PCA9685 16-channel PWM servo driver62.23×25.4×3 mm★ 1 file
SparkFun Qwiic pHAT v2 for Raspberry Pi, isometric render of a generated part
SparkFun Qwiic pHAT v2 for Raspberry Pi65×30.5 mm★ 1 file

Questions

How big is the Pololu DRV8825 stepper driver carrier?

15.24 × 20.32 mm; holes 16 × Ø1.02 mm pin holes on 2.54 mm pitch, rows 12.70 mm apart, 1.27 mm from the edge.
