Specialized Power saddle
What are the dimensions of a Specialized Power saddle? · Modern device · basis: Performance Bicycle listing of the Power Comp: 143 / 155 / 168 mm wide, 240 mm long, 7 × 7 mm rails
Exact dimensions. True size, with no printing tolerance added.
- sizes
- 4 in table
Notes
- A saddle's top is a compound curve with a cut-out: saddle-bag mounts, rail-mounted light and bottle holders and covers need the shape from a scan.
- Published: three widths, 143, 155 and 168 mm; 240 mm long; 7 × 7 mm rails (the standard round-rail size that saddle clamps take).
- A measured Xem scan is planned; until then this page carries only the published numbers and no geometry.
Sizes
| feature | published value | from |
|---|---|---|
| width | 143 / 155 / 168 mm | Performance Bicycle |
| length | 240 mm | Performance Bicycle |
| rails | 7 × 7 mm | Performance Bicycle |
| shell curvature, cut-out | not published | — |
Where the files are
Other publishers' files are linked, not hosted. "verify" = check the license at the link before commercial use.
| Performance Bicycle (retailer listing) | Specialized Power Comp saddle: 143 / 155 / 168 mm wide, 240 mm long, 7 × 7 mm rails | web | reference verify |
Xem scan
Scan planned
When published: mesh $6, STEP $12, ±0.15 mm with a printed fit check. Ask for it and it moves up.
Plain text: sheet.txt · JSON: /api/geometry?object=specialized-power-saddle
You might also need
Questions
How long is a Specialized Power saddle?
240 mm, in 143, 155 and 168 mm widths.
What size are saddle rails?
7 × 7 mm on this saddle.
