Traxxas 3736 ball bearing, 5 × 11 × 4 mm

What size is Traxxas bearing 3736? · Modern device · basis: Maker's parts list (Traxxas)

Also called: Traxxas 3736, traxxas 3736, Traxxas part 3736, 3736 steering blocks, left & right (requires 5x11x4mm bearings), Traxxas 3736 size, Traxxas 3736 dimensions, Traxxas 3736 replacement, repuesto Traxxas 3736, Traxxas 3736 Ersatzteil

Exact dimensions. True size, with no printing tolerance added.

length
11.01 mm
width
11.01 mm
height
4.01 mm

Notes

  • Traxxas part 3736: Steering blocks, left & right (2) (requires 5x11x4mm bearings). Size exactly as printed in Traxxas's parts list; the file is built from that size only.
  • Bearing envelope 5 × 11 × 4 mm (bore × OD × width).
  • True size, no printing tolerance added.

Traxxas 3736 ball bearing, 5 × 11 × 4 mm size chart

dimensionvalue
part numberTraxxas 3736
name (as printed)Steering blocks, left & right (2) (requires 5x11x4mm bearings)
size (as printed)5x11x4mm
bore5 mm
outside diameter11 mm
width4 mm
seals / ballsas printed in the name; not modelled
used inTraxxas Slash 2WD (1/10 short course truck, 58034)

Where the files are

Other publishers' files are linked, not hosted. "verify" = check the license at the link before commercial use.

Traxxas (sheet hosted by JEGS)Slash 2WD Unassembled Kit (Model 58014-4) parts list, REV. 201103 1248, p. 2webPublisher's page; dimensions are facts

Free files

★ Free files 1 parts. Generated by Xem Studio from the standard; threads are plain cylinders at major diameter. CC BY 4.0. index.json

traxxas-3736-steering-blocks-left-right-requires-5x11x4mm-bearings-envelopeBearing envelope 5 × 11 × 4 mm (bore × OD × width)STEP · STL
Let your AI pull this. Add https://xemstudio.com/mcp to Claude, ChatGPT, Cursor or any MCP client (free, no account, one minute) and it can look up exact sizes, mating fits and free STEP/STL from every chat.
Set it up →

Plain text: sheet.txt · JSON: /api/geometry?object=traxxas-3736-steering-blocks-left-right-requires-5x11x4mm-bearings

Traxxas 3736 ball bearing, 5 × 11 × 4 mm, isometric render of a generated part
Render of traxxas-3736-steering-blocks-left-right-requires-5x11x4mm-bearings-envelope from the free STEP; not to scale.
