Traxxas BL-2s 3300 Kv brushless motor

Name: Traxxas BL-2s 3300 Kv brushless motor dimension sheet
Creator: Xem Studio
License: https://creativecommons.org/licenses/by/4.0/

What are the dimensions of the Traxxas BL-2s 3300 Kv brushless motor? · Modern device · basis: Manufacturer specifications (Traxxas)

Also called: traxxas bl-2s motor dimensions, bl-2s 3300kv size, bl-2s motor length, traxxas bl2s motor, medidas motor bl-2s, traxxas bl-2s maße, traxxas bl-2s 3300 kv brushless motor specs, traxxas bl-2s 3300 kv brushless motor measurements, traxxas bl-2s 3300 kv brushless motor size in mm

Exact dimensions. True size, with no printing tolerance added.

length: 36 mm
width: 36 mm
height: 80 mm

Notes

The BL-2s 3300 is Traxxas' 2S brushless motor used in the Fiesta ST Rally BL-2s and other BL-2s models. The file is a Ø36 × 80 mm cylinder.
Can-only length and mounting pattern are not published.
True size, no printing tolerance added. Only published numbers are used; anything not published is said so.

Traxxas BL-2s 3300 Kv brushless motor size chart

dimension	value
Diameter	1.42 in (36 mm)
Length	3.15 in (80 mm)
Shaft	3 mm
Weight	7.51 oz (213 g)
Kv	3300

Where the files are

Other publishers' files are linked, not hosted. "verify" = check the license at the link before commercial use.

Traxxas

Ford Fiesta ST Rally BL-2s 74154-4

web

Publisher's page; dimensions are facts

Free files

★ Free files 1 parts. Generated by Xem Studio from the standard; threads are plain cylinders at major diameter. CC BY 4.0. index.json

traxxas-bl-2s-3300-motor-envelope

Envelope Ø36 × 80 mm (Motor overall length)

STEP · STL
