Pegboard hole size and spacing: 1/4 in holes on 1 in centers (and 3/16 in), panel sizes, hook wire

Name: Pegboard hole size and spacing: 1/4 in holes on 1 in centers (and 3/16 in), panel sizes, hook wire dimension sheet
Creator: Xem Studio
License: https://creativecommons.org/licenses/by/4.0/

What size are pegboard holes? · Standard part · basis: Hardboard pegboard as sold (supplier pages); hook wire gauges from a store-fixture supplier; hooks are a Xem Studio design on that grid

Also called: pegboard hole size, pegboard hole spacing, pegboard hooks 3d print, peg board dimensions

Exact dimensions. True size, with no printing tolerance added.

sizes: 7 in table

Notes

1/4 in hardboard: Ø1/4 in (6.35 mm) holes on 1 in (25.4 mm) centres. Thin board (1/8–3/16 in) takes smaller hooks; check your hole before buying hooks.
A '3/16 × 4 × 8' panel actually measures 0.155 × 47.7 × 95.7 in (3.94 × 1211.6 × 2430.8 mm).
Hook wire: standard 5/32 in (3.97 mm), medium 3/16 in (4.76), heavy 1/4 in (6.35). Hook legs sit one hole (1 in) apart.
Metal pegboard (Wall Control): 20-gauge steel with a 3/4 in stand-off flange, mounting holes on 16 in studs, takes standard 1/4 in hooks.
Printed hooks: PETG, 4 walls; the test strip checks fit before you print a set.

Pegboard hole size and spacing: 1/4 in holes on 1 in centers (and… size chart

item	inch	mm
hole, 1/4 in board	1/4	6.35
hole pitch	1	25.4
actual '3/16' panel thickness	0.155	3.94
hook wire standard	5/32	3.97
hook wire medium	3/16	4.76
hook wire heavy	1/4	6.35
Wall Control stand-off	3/4	19.05

Where the files are

Other publishers' files are linked, not hosted. "verify" = check the license at the link before commercial use.

Forest Plywood	Hardboard pegboard specification	web	Publisher's page; dimensions are facts
The Home Depot (Q&A, listed actual size)	Pegboard panel actual dimensions	web	Publisher's page; dimensions are facts
American Retail Supply	Pegboard hooks: wire gauges	web	Publisher's page; dimensions are facts
Wall Control	Metal pegboard panel	web	Publisher's page; dimensions are facts

Free files

★ Free files 5 parts. Generated by Xem Studio from the standard; threads are plain cylinders at major diameter. CC BY 4.0. index.json

peg-hook-1-4in-reach-25	Printable hook for 1/4 in pegboard (1 in grid), 25 mm reach; prints flat on its side	STEP · STL
peg-hook-1-4in-reach-50	Printable hook for 1/4 in pegboard (1 in grid), 50 mm reach; prints flat on its side	STEP · STL
peg-hook-1-4in-reach-100	Printable hook for 1/4 in pegboard (1 in grid), 100 mm reach; prints flat on its side	STEP · STL
peg-hook-3-16in-reach-50	Printable hook for 1/8 in board with 3/16 in holes, 50 mm reach	STEP · STL
pegboard-test-strip-6x2	Pegboard test strip: 6 × 2 holes Ø6.35 on 25.4 mm centres, 4 mm thick	STEP · STL
